Molex DuraClik 5023510800 Wiring Harness 8 Pin 2.0mm Signal Cable

Custom signal harness built with original Molex 5023510800 8P DuraClik receptacle connector, 2.0mm pitch anti-loose wire-to-board cable assembly. Reinforced dual-latch locking structure resists harsh vibration environments, customizable wire AWG, length and shielding options. Wide temperature endurance and RoHS compliance, stable multi-channel signal interconnection solution for automotive electronics, medical device and industrial automation manufacturers.

Specifications

Advantages

1. Proprietary ISL Double Anti-Loosening Lock Structure (Core Advantage)

   Combines outer audible click snap lock and inner secondary terminal retainer. Dual-layer locking completely solves terminal back-out, partial mating and loose contact problems caused by continuous vibration in automotive and industrial equipment, far more reliable than single-lock ordinary connectors.

2. -40℃ ~ +105℃ High-Temperature Resistant Glass-Filled PBT Housing

   Stable mechanical and insulation performance under extreme temperature fluctuations, suitable for car interior heating parts, oven control panels and high-temperature test equipment without deformation or cracking.

3. Audible Click Mating Confirmation Eliminates Hidden Half-Mating Risks

   Assembly staff can clearly hear and feel the click when fully mated, avoiding invisible partial insertion that leads to unstable signal output and equipment malfunction.

4. Compact 2.0mm Low-Profile 8Pin Multi-Channel Layout

   Slim single-row housing occupies minimal PCB layout space, integrates 8 signal channels in one connector to simplify wiring for multi-sensor equipment and reduce cabinet internal harness clutter.

5. Polarized Anti-Reverse Misplug Protection

   Asymmetric positioning ribs physically block reverse insertion, preventing expensive mainboard IC, sensor driver and automotive control chip burnout from reversed power supply wiring.

6. One-Stop Custom Harness Manufacturing Service

   Support small-batch prototype samples and mass bulk production; finished harnesses can be processed with shielding, tin dipping, heat shrink strain relief and custom label marking for direct assembly on customer production lines.

Application

1. Automotive Interior Multi-Sensor Electronic Modules

   Car instrument panel multi-channel detection signal harness, door control module 8pin DuraClik wiring cable, automotive seat sensor array extension wire, rearview mirror ADAS auxiliary signal assembly

2. Industrial Automation PLC & Micro Detection Equipment

   Small PLC I/O multi-channel input signal jumper, packaging machine multi-photoelectric sensor wiring harness, desktop robot joint multi-signal thin cable, handheld industrial detector control board assembly wire

3. Household Electrical Appliance Multi-Detection Control Panels

   Washing machine multi-sensor 8pin signal harness, refrigerator temperature/humidity array wiring cable, air purifier multi-function detection DuraClik jumper, smart water dispenser touch panel multi-channel wire

4. Portable Medical Electronic Devices

   Home multi-function physical therapy equipment internal signal harness, portable vital sign monitor control board cable, beauty instrument multi-sensor thin wiring assembly, portable ECG detection signal jumper

5. Mini Intelligent IoT & Consumer Hardware

   3D printer mainboard multi-channel extension wire, wireless smart lock control panel signal harness, mini industrial gateway inter-board connecting cable, human body induction multi-sensor DuraClik wiring lead

FAQ

1. What does 5023510800 stand for?

502351 = Molex DuraClik ISL female receptacle housing series; 08 = 8 contact positions; 00 = standard free-hanging crimp housing without extra accessories. It mates with DuraClik series SMT male PCB headers and matching gold-plated DuraClik crimp terminals.

2. How much current can each pin of this 5023510800 anti-loosening harness carry?

Each single pin supports maximum 3A continuous low-current transmission, only applicable to multi-channel sensor signal, indicator light and miniature low-power supply circuits; not suitable for high-power load wiring above 5A.

3. Why is this DuraClik harness called anti-loosening?

It adopts the exclusive ISL inner secondary double lock: the outer latch locks the male plug, and the inner plastic retainer locks the crimp terminal inside the housing. Even under long-term vibration, terminals cannot retreat or fall out, effectively preventing loose contact signal loss.

4. Can we customize double-head wire-to-board jumpers with 5023510800 female on one end and matching DuraClik male PCB header on the other?

Yes, we can produce custom full-length double-head extension jumpers with arbitrary wire length according to customer PCB layout requirements.

5. Can this connector be used in vehicle engine compartment high-temperature environments?

The PBT housing withstands continuous temperature up to 105℃, suitable for automotive interior auxiliary signal circuits; not recommended for direct long-term exposure to engine core heat sources above 110℃.
