Molex 5031491800 CLIK-Mate Connector Cable 1.5mm Pitch Wiring Harness

The core highlight of CLIK-Mate 1.5mm dual-row series lies in its compact double-row layout and inner audible click lock design. The hidden internal locking buckle generates distinct "click" sound once fully mated, allowing operators to confirm complete connection without visual observation, eliminating hidden risks of incomplete insertion that cause intermittent signal loss under long-term vibration. Molded physical polarization ribs on both sides of the housing fully block reverse plugging, avoiding PCB short-circuit and chip burnout during mass assembly lines.

Tuning-fork shaped double elastic contact terminals maintain ultra-stable low contact resistance, and optional gold plating effectively suppresses fretting corrosion caused by alternating cold and heat, ideal for long-running precision sensor signal transmission. Built-in integrated strain relief ribs at the wire outlet disperse bending tension, preventing wire core fracture after repeated swing inside slim narrow equipment cavities. Multi-color coded ultra-thin wires separate 18 independent signal channels clearly to simplify circuit sorting during equipment assembly. All crimp transition joints are wrapped with heat shrink tubing for secondary strain relief protection.

Every finished harness undergoes strict full factory inspection before shipment, including continuity test, terminal pull retention force test, insulation resistance & high voltage withstand test and thermal cycle vibration aging screening. We supply single-end CLIK-Mate finished cables and cross-series conversion harnesses matched with other miniature connectors for consumer electronics manufacturers, medical device R&D teams and industrial automation equipment suppliers.

Specifications

Advantages

• Dual-row 1.5mm ultra-high density miniaturized layout: Double-row design accommodates 18 signal channels within narrow PCB space, greatly reducing control board occupied area, perfectly matching slim portable medical instruments, thin fitness equipment and compact vehicle interior electronic modules with strict space limits.

• Hidden inner audible click locking safety design: Unlike external protruding latches that occupy extra layout space, embedded internal lock produces obvious mating feedback without lateral protrusions, saves equipment internal wiring clearance and avoids accidental disconnection caused by vibration and pulling.

• Multi-tier plating terminal selection matching different usage scenarios: Cost-effective matte tin plating for mass-produced consumer electronic digital signal circuits; uniform gold plating layer inhibits oxidation and signal drift, suitable for precision medical monitoring and long-service-life industrial sensor equipment under alternating temperature environments.

• Halogen-free high-temperature PBT housing material: Meets low-smoke halogen-free export standards for medical and portable electronics, excellent anti-deformation performance during PCB SMT reflow soldering, stable mechanical properties under long-term alternating cold and hot working conditions.

• Integrated strain relief anti-fatigue bending structure: Molded rib structure at the wire outlet disperses repeated bending stress, effectively solving wire breakage faults caused by frequent swing of fitness equipment moving parts and portable device internal wiring.

• Flexible full-range OEM customization service: Support arbitrary wire length adjustment, switching between ordinary PVC and lightweight high-temperature silicone wire, small batch prototype sample orders available for medical equipment, slim consumer electronics and industrial control hardware product development verification.

Application

• Slim Portable Medical Monitoring Instruments:Wearable patient vital sign detector multi-channel sensor signal harness, handheld portable blood parameter analysis equipment internal dual-row thin wire assembly, miniature bedside monitoring module control board high-density signal cable

• Household Fitness & Wearable Consumer Electronics:Multi-function treadmill mainboard multi-sensor integrated wiring, smart body fat scale detection thin signal harness, foldable portable massage equipment internal control dual-row cable, gaming console slim auxiliary board signal jumper wire

• Miniature Industrial Process Control Modules:Compact environmental multi-parameter transmitter 18-channel signal connecting wire, small PLC high-density expansion module thin terminal harness, miniature servo drive auxiliary feedback signal wiring assembly, desktop test bench multi-sensor conversion cable

• Light Commercial Vehicle Interior Auxiliary Electronics:Car ambient light, seat occupancy, door lock integrated multi-signal thin harness, instrument panel miniature control board high-density connecting wire, new energy vehicle low-voltage auxiliary detection signal cable

• Compact Smart Home Slim Control Devices:Ultra-thin intelligent air quality monitor multi-sensor wiring, mini smart cabinet lock integrated detection signal cable, wall-mounted slim smart control panel dual-row high-density signal harness
