Designed exclusively for motor internal signal acquisition, the Sumitomo 6098-5285 wire harness integrates authentic Sumitomo male-female plug connectors with precision-engineered wiring, delivering reliable signal transmission for automotive and industrial motor control systems. This purpose-built solution combines Sumitomo's legendary automotive-grade durability with optimized signal integrity, ensuring accurate data collection from motor windings, sensors, and control modules in high-vibration, harsh environments.
Core Features
✅ Precision Signal Acquisition
2-position (2P) configuration optimized for motor current, temperature, and position signal transmission
Low contact resistance (≤15mΩ) minimizes signal distortion, ensuring data accuracy for ECU calibration
0.64mm² cross-sectional wire (24AWG equivalent) balances flexibility and signal stability
✅ Automotive-Grade Durability
PA66 glass-fiber reinforced housing (UL94 V-0) withstands -40℃ to 125℃ operating temperatures
Tin-plated copper alloy contacts resist corrosion and ensure 500+ reliable mating cycles
Vibration-resistant locking mechanism (15g, 10-2000Hz) prevents disconnection in high-motion motor environments
✅ Secure & Anti-Misplug Design
Polarized rectangular housing with keyed alignment eliminates reverse connection risks
Snug-fit male-female mating interface with audible lock confirmation ensures proper installation
Sealed connector variant (optional) provides IP67 protection against dust and moisture ingress
✅ Seamless System Integration
Compatible with Sumitomo 6098 series connectors and automotive motor control units (MCUs)
Color-coded wiring simplifies polarity identification and assembly
Compliant with automotive manufacturing standards for plug-and-play integration
Application Scenarios
Ideal for motor internal signal acquisition in:
Automotive: Electric vehicle (EV) traction motors, hybrid vehicle (HV) drive motors, power steering motors
Industrial: Servo motors, DC brushless motors, industrial fan motors, pump motors
Transportation: Commercial vehicle motors, railway traction motors, marine propulsion motors
Equipment: HVAC system motors, robotic arm motors, automation line motors
Quality Assurance
Authentic Sumitomo components with full batch traceability
100% continuity, insulation resistance, and contact integrity tested before shipment
Compliant with automotive EMC (Electromagnetic Compatibility) standards
Resistant to oil, grease, and chemical exposure common in motor environments
Customization Options
Custom cable lengths (10cm-500cm) with precise cut-to-length processing
Shielded wiring option for EMI/RFI noise reduction in sensitive signal applications
UL-certified automotive-grade wire (e.g., UL1015, UL1569) for specific temperature requirements
Custom labeling and packaging for mass production lines
Trust the Sumitomo 6098-5285 wire harness for accurate, reliable motor signal acquisition in the most demanding automotive and industrial applications. Contact our technical team for compatibility verification, sample requests, or custom motor-specific configurations.
