JST SMR-10V-B Connector Cable 2.5mm Pitch Wiring Harness SYM-001T-P0.6

The SM series core advantage lies in its stable arm lock structure and high-pressure wiping contact design. After full mating, the elastic arm lock generates obvious tactile locking feedback to resist accidental separation caused by equipment vibration and wire pulling. During plugging and unplugging, the contact surface automatically wipes away dust and oxide layers, maintaining long-term stable conductive performance without intermittent signal faults. Molded physical positioning ribs on both sides of the housing completely block reverse insertion, eliminating PCB short-circuit and component burnout risks during mass assembly lines.

Internal molded elastic lances firmly lock SYM-001T-P0.6 crimp pins inside the housing, with high pull-out resistance to prevent terminal back-out after repeated bending and jolting. Multi-color coded thin wires clearly distinguish power positive/negative, ground and multi-channel sensor signal circuits to simplify circuit sorting during equipment assembly. All crimp transition joints are wrapped with heat shrink tubing for strain relief to avoid wire core fracture at frequent bending positions inside equipment cavities.

Every finished harness undergoes strict full factory inspection before shipment, including continuity test, terminal pull retention force test, insulation resistance & high voltage withstand test and thermal cycle aging screening. We supply single-end finished SMR-10V-B cables, male-female inline extension harnesses and cross-series conversion wiring matched with other standard connectors for home appliance manufacturers, industrial control R&D teams and office equipment production factories.

Specifications

Advantages

• Arm-type tactile locking anti-drop design: Independent elastic arm lock delivers obvious clamping feedback after full mating, far stronger pull resistance than simple friction locks, effectively solving loose contact faults caused by long-term vibration of kitchen appliances and industrial control equipment.

• Self-wiping high-pressure contact terminals: SYM-001T-P0.6 phosphor bronze pins form high contact pressure after docking, automatic surface wiping during plugging removes dust and oxidation, greatly extending service life for equipment requiring frequent disassembly and maintenance.

• Wide wire gauge compatibility balancing power and signal transmission: Supports thick AWG22 wire for 3A auxiliary small power supply loops and thin AWG28 wire for multi-channel weak sensor signal integration, realizing mixed power & signal transmission within one single 10Pin harness to simplify internal equipment wiring layout.

• Black PA6 flame retardant housing with dual installation compatibility: Free-hanging cable layout for internal equipment cavity wiring; housing reserved structural position for panel mounting, compatible with 0.5~2.0mm thickness equipment panels, one housing adapts two mainstream assembly modes to reduce spare part inventory.

• Full physical anti-reverse polarization protection: Integral molded positioning ribs on both sides block reverse plugging from any angle, drastically cut short-circuit defective rate during automated mass production and lower manufacturers’ after-sales maintenance costs.

• Flexible full-range OEM customization service: Support arbitrary wire length adjustment, switching between ordinary PVC and high-temperature silicone wire, small batch prototype sample orders available for kitchen appliance, industrial control and office equipment product development verification.
