TE 643813-5 UAV Robot Wire Harness 2.54mm IDC Cable

The core advantage of this harness lies in its IDC piercing quick connection structure. The slotted contact blade directly cuts through wire insulation to form stable metal-to-metal conduction, removing tedious stripping processing steps and reducing wire core damage risks during assembly, perfectly matching mass production of UAV and robot electronic modules. The housing integrates integrated strain relief ribs to disperse bending tension at the wire outlet, avoiding conductor breakage under frequent swing vibration of robot joints and drone flight vibration. Molded physical anti-mismate ribs on both sides completely block reverse insertion, preventing flight control board short-circuit and drone flight failure risks during equipment assembly.

Internal elastic locking lances firmly clamp IDC contacts inside the shell with strong pull-out resistance, resisting long-term continuous jolting and vibration of aerial and robotic equipment. Multi-color coded thin lightweight wires effectively reduce overall load weight of multi-rotor drones while clearly separating sensor feedback, communication and auxiliary power signal channels. All IDC piercing joints are reinforced with shrink tubing for secondary anti-fatigue protection.

Every finished harness undergoes strict factory full inspection before shipment, including continuity test, terminal pull retention force test, high voltage withstand test, low-temperature vibration aging screening and repeated bending cycle test. We supply single-end finished IDC cables and cross-series conversion wiring matched with other miniature connectors for UAV flight control manufacturers, industrial robot R&D teams and automated equipment suppliers.

Specifications

Advantages

• IDC one-step piercing connection high-efficiency design: Abolish wire stripping work, greatly shorten UAV and robot module assembly time; precision slotted tin contacts form tight conductive contact without damaging inner copper strands, stable signal transmission under long-term vibration.

• Lightweight low-vibration structural optimization: Thin thin-gauge matching wire + compact red nylon shell greatly reduce total wiring weight, critical for multi-rotor drone load control; built-in strain relief eliminates wire fracture caused by robot joint reciprocating swing and aerial flight bump vibration.

• Ultra-wide temperature adaptive performance: Stable working range from -55℃ low altitude cold air to 105℃ equipment heat accumulation, no hardening or contact failure when drones fly in alpine regions or robot control cabinets run continuously at high load.

• Physical full anti-reverse misplug protection: Integral molded positioning ribs on housing sides block reversed mating from any angle, avoid flight control board short-circuit crash and robot servo signal loss defects during mass assembly.

• Graded 5A large current carrying capacity: Supports both multi-channel weak sensor signal transmission and miniature servo auxiliary power supply integration, one single 5Pin harness completes mixed power and signal wiring to simplify drone and robot internal messy circuit layout.

• Lightweight customized service oriented to aerial intelligent equipment: Support ultra-short 0.05m ultra-light wiring for drone compact cavity layout, lightweight silicone wire option to further reduce flight load, small batch prototype sample orders available for UAV and robotic equipment development verification.

Application

• Multi-Rotor UAV Aerial Flight Control Systems:Drone flight control board gyroscope acceleration sensor signal harness, airborne camera image feedback thin IDC cable, ESC electronic speed regulator auxiliary detection connecting wire, GPS positioning module low-weight signal terminal wire

• Collaborative & Small Industrial Robots:Desktop small six-axis robot servo motor feedback signal wiring, AGV mobile robot obstacle avoidance sensor internal harness, automated assembly manipulator joint swing thin control cable, robot vision camera trigger signal IDC wire

• Intelligent Automated Testing Equipment:Small automatic sorting machine proximity sensor connecting harness, desktop test bench motion control board signal jumper wire, miniature automatic dispensing machine servo drive thin terminal cable

• Portable Intelligent Detection & Survey Equipment:Outdoor terrain survey portable sensor control wiring, handheld industrial detection equipment mainboard cross-board IDC conversion cable, portable laser ranging module signal transmission harness

• Miniature Educational Robot & Teaching UAV Hardware:Student programming educational robot mainboard sensor connecting wire, small training drone airborne auxiliary module signal harness, single-chip intelligent car motion control thin IDC wiring assembly
