This wiring harness adopts a 2.5mm pitch Mini-Lock crimp connector system, matching 511630700 connector housing with 507528200 crimp terminals. It is a compact wire-to-board and wire-to-wire connection solution, featuring reliable anti-vibration locking, polarized anti-misplug structure and stable crimp connection, widely used for low-current signal and power transmission in automotive subsystems, household appliances and compact electronic equipment.
Key Features & Advantages
Compact Mini-Lock Structure
2.5mm standard pitch provides high-density wiring in limited internal space, suitable for miniaturized product design.
Secure Locking Latch
Built-in locking buckle prevents accidental disconnection caused by vibration and mechanical shock.
Polarized Anti-Misplug Design
Asymmetric housing structure avoids reverse mating, effectively protecting circuits and electronic components.
Stable Crimp Connection
507528200 crimp terminals form a reliable connection with wires, featuring low contact resistance and high pull-out force.
Wide Temperature Resistance
Adaptable to high and low temperature environments, meeting the requirements of automotive and industrial applications.
Flexible Wiring
Compatible with thin-gauge wires, offering excellent flexibility for routing in curved and narrow spaces.
Typical Applications
Automotive interior electronics: lighting modules, small sensors, dashboard accessories
Internal wiring of household appliances such as air conditioners, small fans and kitchen electronics
Consumer electronic device control module connections
Low-power signal transmission for industrial control equipment
Battery management and low-voltage power harness for portable devices
Quality Assurance & Customization
100% electrical continuity, insulation resistance and terminal pull-out force testing before shipment
Customizable cable length, wire color and wire arrangement
Optional heat-shrink tubing for enhanced strain relief
Stable crimping process ensures long-term connection reliability
Eco-friendly materials compliant with global environmental standards
