Molex 5031492400 Connector Cable 5025790000 24P 1.5mm Terminal Wire Assembly

This 24-pin wire-to-board cable assembly belongs to Molex's CLIK-Mate™ series, featuring a 1.5mm pitch dual-row plug housing (503149-2400) and 502579-0000 male crimp terminals. Designed for reliable signal and power transmission in compact electronic devices, it provides a secure, plug-and-play wiring solution for internal connections in consumer electronics, industrial equipment, and automotive systems. The assembly combines robust mechanical retention with high electrical performance, ensuring stable operation in demanding environments.

Key Features & Advantages

• Secure CLIK-Mate Locking System

  Integrated positive lock provides audible and tactile confirmation of proper mating, preventing accidental disconnection due to vibration or shock.
• Dual-Row High-Density Design

  1.5mm pitch dual-row configuration delivers 24 connection points in a compact footprint, maximizing space efficiency in crowded PCBs.
• Reliable Crimp Termination

  502579-0000 terminals ensure gas-tight, low-resistance connections with 24–28 AWG wires, minimizing voltage drop and signal loss.
• Polarized Anti-Misinsertion Design

  Asymmetric housing geometry and keying prevent reverse mating, protecting both the connector and PCB from damage during installation.
• Robust Environmental Performance

  LCP housing withstands high temperatures and chemical exposure, while tin plating provides excellent corrosion resistance for long-term reliability.
• Tool-Compatible Assembly

  Designed for use with Molex crimp tools (e.g., 63819-4600 series) for consistent, professional-quality terminations.

Typical Applications

• Consumer electronics: Set-top boxes, gaming consoles, home appliances, and smart devices

• Industrial automation: PLCs, sensors, control panels, and instrumentation

• Automotive electronics: Infotainment systems, lighting controls, and sensor modules

• Medical devices: Patient monitors, diagnostic equipment, and portable medical instruments

• Office equipment: Printers, scanners, and multi-function devices

• Communication devices: Routers, modems, and network switches

Quality Assurance & Customization

• 100% electrical continuity and insulation resistance testing

• Automated crimping process ensures consistent terminal position and contact force

• Customizable cable lengths (standard options: 100mm, 200mm, 300mm, 500mm)

• Optional wire colors for easy circuit identification

• Custom pinouts available for specific application requirements

• RoHS-compliant materials with lead-free construction
