This finished wiring assembly is built around Molex genuine 5040510501 (504051-0501) female crimp housing, belonging to the mini Pico-Lock 1.5mm interconnect system with single-row 5 circuits. All terminals are precision machine-crimped with gold-plated copper contacts for ultra-low contact resistance, paired with thin stranded electronic wires for slim equipment internal wiring.
Unique side polarization ribs eliminate reverse mating damage, while compact low-profile structure saves PCB installation space. Every harness passes continuity test, terminal pull-out test and high voltage withstand inspection, perfectly mating with 504050 series SMT PCB headers for stable signal & low-power power transmission in miniature electronic devices.
| Housing PN | Molex 5040510501, 5P single row, 1.5mm pitch |
| Matching Terminal | Molex 504052 crimp terminal(AWG24-32) |
| Electrical Rating | 3A Per circuit,150V DC Max |
| Working Temperature | -40℃ to +105℃ |
| Core Design | Polarization anti-mismate,halogen-free PA housing |
| Custom Service | Wire length,AWG,single/double-end connectors |
Advantages
Ultra-slim low-profile design: Only 2mm mated height, ideal for ultra-thin notebooks, displays and compact sensors with limited internal space.
Anti-mismating polarization structure: Side guide ribs prevent reverse plugging to avoid short-circuit and circuit board burnout.
Stable gold-plated contact system: Max acontact resistance ≤20mΩ, consistent signal transmission without intermittent faults.
High-temperature halogen-free housing: PA material resists aging, meets strict environmental export standards for global markets.
Reliable crimp performance: Min terminal retention force 6.7N, no terminal back-out under vibration and frequent plugging.
Reliable crimp performance: Min terminal retention force 6.7N, no terminal back-out under vibration and frequent plugging.
Application
Consumer Mini Electronics:Laptop internal sensor wiring, tablet control board harness, LCD/LED display signal cables
Industrial Automation:Mini proximity sensors, smart meter internal wiring, small power supply signal wire
Automotive Interior Electronics:Car infotainment auxiliary signal harness, interior small control module wiring
Medical & Smart IoT:Wearable health monitoring equipment wiring, miniature smart home sensors
FAQ
Q1: Which terminals match Molex 5040510501 harness?
A: It exclusively supports Molex 504052 series crimp terminals, compatible with AWG24 to AWG32 thin stranded wires.
Q2: Can this harness be used for ultra-thin notebook internal wiring?
A: Yes, its 2mm low mated height perfectly adapts to narrow internal gaps of slim laptops and flat displays.
Q3: What is the maximum current each pin can carry?
A: Each circuit supports stable 3A continuous current under normal operating temperature.
Q4: Can I order small prototype samples for testing?
A: Small sample orders are available; mass production MOQ can be negotiated for long-term OEM cooperation.
