Designed for reliable wire-to-wire connectivity in space-constrained applications, this precision-engineered assembly pairs the JST XADRP-08V dual-row plug housing with SXA-001T-P0.6 crimp terminals—delivering exceptional signal integrity and mechanical stability. Its 2.5mm pitch design and 8-circuit configuration optimize board space, while the secure locking structure ensures vibration-resistant performance in critical systems.
Core Features & Advantages
✅ Compact High-Density Design: 2.5mm pitch double-row layout supports 8 circuits in a slim footprint, ideal for space-limited devices requiring multiple connections
✅ Secure Locking Mechanism: Positive latching system prevents accidental disconnection, enhanced by inner-type contact lances that ensure strong terminal retention (≥40N pull-out force)
✅ Reliable Electrical Performance: Tin-plated phosphor bronze contacts (reflow-treated) support 3A maximum current (20 AWG) and 250V AC/DC voltage, with contact resistance ≤15 milliohms
✅ Panel-Mount Compatibility: Integrated panel-mount ears enable secure fixture installation, simplifying assembly in industrial equipment and consumer electronics
✅ Compliance & Durability: RoHS 2 (2015/863/EU) certified housing (PA66, UL 94V-0) resists environmental stress, while error-proof polarization eliminates mis-mating risks
Versatile Applications
Optimized for cross-industry connectivity needs:
Consumer Electronics: 3D printers, gaming consoles, home appliances (washing machines, air conditioners)
Industrial Control: Sensor modules, PLC interfaces, automation equipment (conveyor systems, robotic arms)
Medical Devices: Non-implantable diagnostic tools (blood pressure monitors, ultrasound accessories)
Smart Home: IoT devices, lighting controllers, security system panels
Seamlessly mates with JST XAD series PCB headers and receptacle housings for complete wire-to-board/wire-to-wire solutions
Quality Assurance
Backed by JST’s legacy of precision interconnect technology, this assembly offers:
Tool-compatible crimp termination (works with JST-approved crimp applicators) for consistent installation quality
Impact-resistant housing and vibration-proof locking structure for long-term reliability in mobile or high-shock environments
Halogen-free construction (per RoHS 2 standards) for eco-friendly infrastructure
Wide availability of matching components (retainers, PCB headers) for scalable system design
