Mx 503149 Series Clik-Mate Plug 1.50mm Pitch Dual-Row Connector Wiring Harness

Molex 503149 Series Clik-Mate Plug 1.50mm Pitch Dual-Row Connector Wiring Harness

Status Active

Category Connector Housings

Series 503149

Description CLIK-Mate Plug Housing, 1.5mm Pitch, Dual-Row, Positive Lock, White

Application Signal, Wire-to-Board

Product Name CLIK-Mate

Model:
Molex 5031491800 Cable Assembly
Brand:
Huamao
Code:
HM10926A

Availability:

Quantity:



Inquire Add to Basket Buy at Amazon

Mx 503149 Series Clik-Mate Plug 1.50mm Pitch Terminal Connectors Dual-Row Connector molex 503149 connector cable cable assembly Wire Harness

Product Description

Engineered for high-density connectivity in demanding industrial, automotive, and consumer electronics applications, this custom-built Molex 503149 Series Clik-Mate wiring harness leverages Molex’s iconic Clik-Mate plug design and 1.50mm ultra-fine pitch dual-row connector architecture. Delivering uncompromising signal integrity and power transmission, it serves as a critical connectivity solution for space-constrained devices, complex electronic systems, and industrial equipment where reliability and efficiency are non-negotiable.

Core Performance & Key Features

Molex 503149 Series Authenticity: Features genuine Molex 503149 Series Clik-Mate plugs, engineered to Molex’s proprietary design standards for flawless mating and consistent electrical performance. The Clik-Mate system enables tool-free, snap-in installation—streamlining assembly processes and reducing labor costs for manufacturing workflows.
1.50mm Dual-Row Density Design: The 1.50mm pitch dual-row connector maximizes connectivity in compact electronic enclosures, doubling signal/power capacity compared to single-row alternatives of the same footprint. Ideal for devices where space optimization is a top priority, without sacrificing performance.
Superior Material Construction: Equipped with high-purity copper core wiring for low-resistance power transfer and minimal signal loss, paired with tin-plated terminals for exceptional corrosion resistance. Insulated with flame-retardant, heat-resistant polymer materials rated for -40°C to 125°C operating temperatures, ensuring durability in extreme industrial, automotive, and environmental conditions.
Customizable Configuration: Fully flexible OEM/ODM design to match your specific application needs—adjustable wire length, custom wire gauge (28AWG–22AWG), custom terminal types, color-coded wiring for easy installation, and integrated strain relief for rugged use. Supports rapid prototyping and high-volume bulk production for small-batch to large-scale projects.
Robust Reliability Testing: Each harness undergoes rigorous quality verification, including 5000+ mating cycle durability tests, vibration resistance assessments (per ISO 16750), signal stability checks, and environmental stress trials (temperature cycling, humidity exposure). Compliant with international safety standards (UL, ISO 9001) to meet industry-grade reliability benchmarks.
Dual-Function Connectivity: Seamlessly balances high-current power transmission and high-speed signal transfer, making it suitable for mixed-signal systems that require both stable power delivery and precise data communication—eliminating the need for separate harnesses and simplifying system integration.

Ideal Application Scenarios

This Molex 503149 Series 1.50mm dual-row Clik-Mate wiring harness is the preferred connectivity solution for:

Industrial Automation: PLC controllers, servo drives, sensor arrays, industrial control panels, and robotic arms.
Automotive Electronics: On-board diagnostic (OBD) systems, in-vehicle infotainment, LED lighting modules, and sensor networks (e.g., ADAS auxiliary sensors).
Precision Consumer & Medical Electronics: Smart home control hubs, medical diagnostic equipment, wearable devices, and high-end audio/video systems.
Communication & IoT Infrastructure: Network switch modules, IoT gateway devices, and wireless communication base stations.
Small-Scale New Energy Devices: Portable power stations, battery management systems (BMS) for compact energy storage, and solar-powered IoT sensors.

Uncompromising Quality & Compliance

Backed by Molex’s global reputation for precision connector engineering, our 503149 Series Clik-Mate wiring harnesses are manufactured in ISO 9001-certified facilities to ensure consistent quality. Every unit is inspected for connector fitment, wire integrity, and electrical performance to meet the strict safety and reliability requirements of professional electronics manufacturing. Whether for low-volume prototype runs or mass production for industrial and automotive clients, we deliver Molex-grade harness solutions that align with your project’s performance and compliance goals.

Partner for Tailored Connectivity Solutions

We specialize in custom Molex connector harness manufacturing, offering end-to-end support from design consultation and prototyping to mass production and quality assurance. Work with our engineering team to optimize the 503149 Series Clik-Mate harness for your specific device’s power, signal, and space requirements—ensuring seamless integration and long-term performance in your target applications.
