This custom cable assembly adopts genuine JST ZPDR-26V-S dual-row connectors with a precise 1.5mm pitch, professionally engineered as dedicated audio reception wiring for high-density electronic audio systems. Designed for stable audio signal transmission and anti-interference performance, this harness fits perfectly with PCB mounting layouts while ensuring secure connection locking for long-term stable operation.
Core Structural & Electrical Specifications
Built on the reliable JST ZPD connector system, the 26-position receptacle housing features an integrated anti-drop locking mechanism to avoid accidental disconnection during device vibration and movement.
Pitch dimension: standard 1.5mm compact spacing for high-density circuit design
Rated current: 2A continuous working current for low-power audio signal transmission
Temperature tolerance: operating range from -25°C to 85°C to adapt indoor and enclosed equipment environments
Connector material: UL94V-0 flame-retardant PBT housing with tin-plated alloy terminals for stable contact conductivity
Compatible wire gauge: supports 24AWG to 28AWG flexible stranded copper wires for audio signal conduction
Professional Audio Performance Advantages
We optimize every detail specifically for audio reception scenarios to reduce signal attenuation and external electromagnetic interference. Each terminal undergoes automated precision crimping to maintain consistent contact resistance and clear audio transmission quality. The overall wiring layout is streamlined to minimize noise interference, ensuring pure sound output for audio modules and peripheral receiving circuits.
Customization Options
We offer full personalized processing tailored to your project requirements: adjustable cable total length, single or dual-end terminal processing, tin dipping reinforcement, and customized wiring sorting. Shielded audio wire upgrades are available for high-interference industrial audio environments to further enhance signal stability. All non-standard drawings and sample replication services are supported for special installation structures.
Quality Compliance & Strict Testing
All raw materials fully comply with RoHS and REACH environmental standards for global export markets. Every finished harness passes 100% continuity testing, locking structure durability inspection and aging resistance verification before delivery, guaranteeing consistent quality for mass installation use.
Application Scenarios
Ideal for audio receiving modules, smart speaker internal wiring, multimedia player circuits, automotive audio accessories, household entertainment equipment and compact industrial audio control systems that require 1.5mm high-density JST ZPD connection solutions.
Custom Service Support
Low MOQ supports trial orders and bulk production arrangements. Our engineering team provides one-on-one technical matching advice to help you confirm connector assembly and wiring specifications quickly. Send your detailed requirements now for an instant professional quotation.
