This pre-assembled jumper cable is a cross-model conversion wire designed for RC servo power connection, featuring JST SYP 2P male connector and SM 2P female receptacle. Precision machine crimped tin-plated terminals eliminate cold solder faults, paired with soft 20AWG silicone stranded wire that resists repeated bending. Integrated locking tabs on both connector housings stop accidental disconnection during vehicle acceleration, motor vibration or robot movement. Every finished cable passes continuity and pull force testing, serving as a universal conversion harness to match different brand servo, ESC and lithium battery ports for remote-controlled models and small intelligent robots.
| Connector Configuration | JST SYP 2P Male to SM 2P Female |
| Wire Specification | 20AWG high-temperature silicone wire |
| Rated Parameter | 3A continuous,max 60V DC |
| Operating Temperature | -40℃ to +125℃ |
| Lock Structure | Built-in snap anti-drop buckle |
| Custom Options | 50-800mm length，multi-color wire，single/double end change |
Advantages
Cross-spec conversion design: Connect SYP and SM ports seamlessly, solve incompatible port issues for RC model modification.
20AWG thick silicone wire: Low voltage drop, strong overcurrent capacity, less heat during high-load servo operation.
Super flexible silicone insulation: Anti-crack and anti-aging, suitable for frequent bending inside compact model fuselages.
Secure snap lock design: Firm locking avoids loose connection caused by bump, shake or rapid steering of RC vehicles.
Automated crimp processing: Consistent terminal retention force, no poor contact or terminal withdrawal failures.
Complete custom support: Adjustable cable length and wire color to meet personalized modification demands of model hobbyists.
Application
RC Vehicle Models: Off-road RC cars, crawlers, drift vehicles servo power extension wires
Multi-Rotor & Fixed-Wing Drones: Mini UAV steering servo conversion jumper cables
Intelligent Robot Equipment: Small servo robots, educational coding robot internal connecting wires
Hobby Electronic Accessories: ESC, LiPo battery, model steering gear cross-port adapter cables
FAQ
Q1: What is the maximum continuous current of this SYP to SM cable?
A: With standard 20AWG silicone wire, the cable stably supports 3A continuous current for servo power supply.
Q2: Can I customize different lengths of this conversion cable?
A: Custom lengths ranging from 50mm to 800mm are available, extra long sizes negotiable for bulk orders.
Q3: Will the connectors come loose during high-speed RC driving?
A: Both SYP and SM connectors are equipped with snap lock buckles to resist vibration and impact for tight connection.
Q4: Can I get prototype samples for model product testing?
A: Small sample orders are supported, mixed lengths and wire colors are acceptable for prototype verification.
