This specialized cable assembly features the 2298721-9 Mini Fakra 4-in-1 MATE-AX Z-code connector, designed specifically for BYD automotive reversing camera systems. It serves as a critical high-speed data transmission link between the vehicle's rearview camera module and infotainment display, enabling clear, real-time video feed for parking assistance and collision avoidance systems. The 4-in-1 configuration consolidates multiple LVDS (Low-Voltage Differential Signaling) channels into a single compact connector, optimizing space utilization in modern vehicle architectures while ensuring reliable performance in harsh automotive environments.
Key Features & Advantages
1. Original MATE-AX Mini Fakra Technology
Genuine 2298721-9 connector ensures perfect compatibility with BYD vehicle systems
Z-code color-coding prevents misconnection with other vehicle systems
MATE-AX interface delivers superior RF performance compared to traditional SMA connectors
2. 4-in-1 LVDS Channel Integration
Combines 4 independent high-speed data channels in a single compact housing, reducing cable clutter
Supports full HD video transmission for reversing cameras (up to 1080p resolution)
Optimized for LVDS signals, minimizing electromagnetic interference (EMI) and crosstalk
3. Automotive-Grade Durability
Robust PA66 GF30 housing withstands extreme temperatures, vibration, and chemical exposure
Wide operating temperature range (-40°C to +105°C) ensures performance in all climates
Secure snap-on locking mechanism maintains connection integrity during vehicle operation
4. High-Speed Signal Integrity
50Ω impedance matching minimizes signal reflection and attenuation
Silver-plated contacts ensure low contact resistance and long-term reliability
Excellent return loss characteristics for clear, artifact-free video transmission
5. BYD-Specific Design Optimization
Precisely engineered for BYD reversing camera mounting positions and wiring harness routes
Plug-and-play compatibility with BYD infotainment systems and camera modules
Space-saving design fits within the tight constraints of modern vehicle rear-end assemblies
Typical Applications
BYD Reversing Camera Systems: Primary connection between rearview camera and central display unit
360° Surround View Cameras: Data transmission for multi-camera parking assistance systems
ADAS (Advanced Driver Assistance Systems): Video feed for collision avoidance and cross-traffic detection
Infotainment Integration: Link between external camera modules and in-car entertainment displays
Commercial Vehicle Camera Systems: Suitable for BYD electric buses and trucks requiring multiple camera inputs
Quality Assurance & Customization
100% performance testing including signal continuity, impedance matching, and return loss measurement before shipment
Customizable cable lengths (typically 1.5m-3m for BYD applications) and termination options
Waterproof and dustproof variants available for exterior camera installations
Compliant with IATF 16949 automotive quality management standards
Supports OEM/ODM requirements for BYD automotive manufacturers
100% RoHS compliant, free from hazardous substances
This cable assembly represents a premium solution for BYD's advanced reversing camera systems, leveraging industry-leading Mini Fakra technology to deliver reliable, high-performance data transmission in the demanding automotive environment.
